Genomic profiling of CHEK2*1100delC-mutated breast carcinomas



CHEK2*1100delC is a moderate-risk breast cancer susceptibility allele with a high prevalence in the Netherlands. We performed copy number and gene expression profiling to investigate whether CHEK2*1100delC breast cancers harbor characteristic genomic aberrations, as seen for BRCA1 mutated breast cancers.


We performed high-resolution SNP array and gene expression profiling of 120 familial breast carcinomas selected from a larger cohort of 155 familial breast tumors, including BRCA1, BRCA2, and CHEK2 mutant tumors. Gene expression analyses based on a mRNA immune signature was used to identify samples with relative low amounts of tumor infiltrating lymphocytes (TILs), which were previously found to disturb tumor copy number and LOH (loss of heterozygosity) profiling. We specifically compared the genomic and gene expression profiles of CHEK2*1100delC breast cancers (n = 14) with BRCAX (familial non-BRCA1/BRCA2/CHEK2*1100delC mutated) breast cancers (n = 34) of the luminal intrinsic subtypes for which both SNP-array and gene expression data is available.


High amounts of TILs were found in a relatively small number of luminal breast cancers as compared to breast cancers of the basal-like subtype. As expected, these samples mostly have very few copy number aberrations and no detectable regions of LOH. By unsupervised hierarchical clustering of copy number data we observed a great degree of heterogeneity amongst the CHEK2*1100delC breast cancers, comparable to the BRCAX breast cancers. Furthermore, copy number aberrations were mostly seen at low frequencies in both the CHEK2*1100delC and BRCAX group of breast cancers. However, supervised class comparison identified copy number loss of chromosomal arm 1p to be associated with CHEK2*1100delC status.


In conclusion, in contrast to basal-like BRCA1 mutated breast cancers, no apparent specific somatic copy number aberration (CNA) profile for CHEK2*1100delC breast cancers was found. With the possible exception of copy number loss of chromosomal arm 1p in a subset of tumors, which might be involved in CHEK2 tumorigenesis. This difference in CNAs profiles might be explained by the need for BRCA1-deficient tumor cells to acquire survival factors, by for example specific copy number aberrations, to expand. Such factors may not be needed for breast tumors with a defect in a non-essential gene such as CHEK2.

Peer Review reports


Approximately 10–15 % percent of all breast cancer cases arise within a familial clustering of multiple breast cancer cases. Inherited germ-line mutations in the high risk genes BRCA1, BRCA2, and PALB2 are identified in approximately 20 percent of these breast cancer families. In addition, mutations in the CHEK2, ATM and BRIP1 genes confer a moderate lifetime risk of breast cancer but are rare and account for less than 5 % of familial breast cancer cases [1, 2].

CHEK2*1100delC is a moderate-risk breast cancer susceptibility allele with a relatively high prevalence in the Netherlands of 1.1 % in the general population, 2.5 % in unselected breast cancer cases, and 4.9 % in familial breast cancer cases. Other mutations in the CHEK2 gene contributing to breast cancer risk are negligible in the Dutch population. The lifetime risk of breast cancer for a female CHEK2*1100delC mutation carrier from the general population is 20–25 %, increasing to 35–45 % in a familial breast cancer setting [35].

CHEK2 (Checkpoint kinase 2) has been shown to be involved in cell cycle control and DNA damage response. ATM (Ataxia telangiectasia mutated) phosphorylates CHEK2 in response to DNA damage, resulting in CHEK2 homodimerization. The resulting active kinase exerts its function through its ability to phosphorylate TP53, CDC25A, CDC25C, PLK and BRCA1 [6]. The function of CHEK2 is abrogated by the 1100*delC frameshift mutation which causes a premature translation stop in the kinase domain of the protein. Both the mRNA, which is degraded through nonsense-mediated mRNA decay, as well as the resulting truncated protein are highly unstable [7, 8]. Very few breast tumors from 1100delC carriers show CHEK2 protein expression although LOH of the wild-type allele is infrequently found [9]. In contrast, LOH of the BRCA1 gene is frequently reported in BRCA1-mutated breast cancers [10]. Also, BRCA1 mutated breast tumors are frequently reported to be of the basal-like intrinsic subtype, opposed to breast tumors from CHEK2 mutation carriers, which are reported to be mostly steroid hormone receptor positive (progesterone receptor/progesterone receptor (ER/PR) positive) [11]. In accordance, gene expression profiling assigns tumors from CHEK2 mutation carriers to the luminal intrinsic subtypes [12].

We and others have shown specific somatic profiles of CNAs characteristic for both BRCA1 and BRCA2-associated breast carcinomas [1317]. These CNAs are thought to reflect specific oncogenic pathways in tumor development. The identification of driver genes in these genomic regions could lead to a better understanding of the underlying process of tumorigenesis and may provide novel clues for targeted therapies.

In this study we have performed high-resolution copy number, LOH and gene expression profiling of 120 familial breast carcinomas selected from a larger cohort of 155 familial breast tumors, including BRCA1, BRCA2 and CHEK2 mutant tumors. Samples were selected for low amounts of tumor infiltrating lymphocytes (TILs) by mRNA profiling because TILs have detrimental effects on genomic profiling of tumor material [18]. To ascertain whether CHEK2*1100delC breast cancers harbor characteristic genomic aberrations, as seen in BRCA1 mutated breast cancers, we specifically compared the genomic profiles of 14 CHEK2*1100delC breast cancers and 34 BRCAX breast cancers of the luminal intrinsic subtypes for which both SNP-array and gene expression data is available. We compared our results with previously reported findings on genomic and gene expression profiling of CHEK2*1100delC breast cancers [19].


Ethics statement

This study has been approved by the medical ethical committee at Erasmus MC, and was performed according the Code of Conduct of the Federation of Medical Scientific Societies in The Netherlands. Anonymous or coded use of redundant tissue for research purposes is part of the standard treatment agreement with patients in our hospitals, and informed consent was therefore not required [20].

Sample collection

Fresh-frozen specimens of primary breast tumors from female familial breast cancer cases were selected from the tissue bank of the Erasmus Medical Center Rotterdam. All cases had been screened for germ line mutations in BRCA1, BRCA2 and for the CHEK2*1100delC mutation. The complete breast cancer cohort consists of 155 primary tumors and includes 26 tumors with a CHEK2*1100delC mutation, 47 BRCA1-mutated tumors, 6 BRCA2-mutated tumors, and 76 BRCAX tumors. These BRCAX breast cancer cases all originated from families with at least two breast cancer cases in first or second degree relatives of which at least one had been diagnosed before the age of 60. The entire cohort has been described in detail [12, 18]. In this study, 120 tumor samples for which both SNP array and gene expression data is available were used for further analyses. The gene expression and SNP microarray data have been deposited in NCBI's Gene Expression Omnibus and are accessible through GEO Series accession number 54219.

Gene expression microarrays

For gene expression analysis. CEL files of the individual samples as deposited in GEO 54219 were used. The data was analyzed in Partek Genomics Suite (v6.6, Partek Inc.). Detection of differential gene expression was performed by ANOVA analysis, genes with FDR-stepup (false discovery rate) p-values less than 0.05 were considered to be statistically significant differentially expressed.

Classification of intrinsic molecular subtypes

The intrinsic gene list was used to appoint the samples to molecular subtypes as described [12]. In short, the intrinsic gene list [21] was mapped to the corresponding probe-sets on the HGU_133_plus_2.0 array using Unigene Cluster Id's. The most variable probe-sets were used to cluster 120 familial samples using average linkage hierarchical clustering with correlation as a distance metric. In this paper, the luminal A and B samples together are referred to as luminal samples.

mRNA based sample selection

To select for samples with relative low number of TILs, hierarchical clustering of expression data was used. This approach has largely been described in our previous work [18]. In short, the proportion of lymphocytic nuclei of 96 tumor samples was assessed on H&E-stained frozen sections. For subsequent mRNA analysis, the luminal and basal samples were processed separately. These samples were divided in two groups based on the TIL percentages (high and low TIL count, median split) on which subsequent ANOVA analysis was performed to find differentially expressed probe sets passing a FDR p-value <0.05. Finally, the overlapping probe-sets for the luminal and basal sample sets were determined to create the final mRNA immune signature, see Additional File 1. Following this approach, 14 out of a total of 17 CHEK2* 1100delC and 34 out of a total of 49 BRCAX breast cancers with relative low levels of this expression signature were selected for further supervised analyses.

Copy number analyses by SNP arrays

For copy number and LOH analyses, CEL files of the individual samples as deposited in GEO 54219 were used. The array intensity. CEL files were processed by Partek Genomics Suite using default settings for background correction and summarization, results were corrected for GC-content and fragment length. Unpaired copy number analysis was performed in Partek Genomics Suite, comparing signal Log2 ratios to a custom created reference baseline of 90 female HapMap samples with European ancestry (CEU). The genomic segmentation algorithm was used to detect breakpoint regions and estimate copy number levels with stringent parameters (P < 0.0001, >20 markers, signal/noise: 0.45). With an expected normal range of 2 ± 0.25 copies. Differences between the tumor groups (mutation class) for frequency of copy number aberrations (gained, lost, or unchanged) were calculated by employing a 3 x 2 Fisher’s exact test (FE). Resulting p-values were not directly corrected for multiple testing. SNP array, gene and cytogenetic band locations are based on the hg19 Genome build. For unsupervised hierarchical clustering of copy number data the called copy number states (amplification (copy number >6), gain, loss or neutral) of the segmentation data were used as distance metric. Agglomerative clustering was performed on these data by Euclidean distance and Wards method.

LOH calling by detection of allelic imbalance

A segmentation based approach of allelic imbalances was used to identify regions of LOH. The B-allele frequencies of the breast tumor samples were generated in Partek Genomics Suite. Mirrored B-allele frequency (mBAF) profiles were used as previously described [22]. The resulting mBAF profiles were segmented in Partek Genomics Suite and LOH calling of segmented regions was done by applying a fixed allelic imbalance threshold of 0.76 and p-value <0.01. The same parameters used in segmentation of the copy number data were applied, except that a window size of 100 SNPs instead of 20 SNPs was used as a minimum number of genomic markers.


Sample selection for low amount of TILs

To select for samples with low number of TILs, hierarchical clustering of expression data of all 120 breast carcinomas based on the mRNA immune signature was used (Fig. 1a). Relative high numbers of TILs were predominantly found in basal-like breast cancers. However, 14 BRCAX and three CHEK2*1100delC samples of the luminal breast cancers were also found to have such high mRNA signature values and were not used in supervised class comparison of CNAs and differential gene expression analysis. Fig. 1b shows the correlation between immune signature mRNA values and TIL percentages as determined on H&E stained slides (rs = 0.74, p-value < 0.001).

Fig. 1

Hierarchical clustering of immune signature mRNA data and correlation with TILs. a, hierarchical clustering of mean centered, standardized immune signature gene expression data. Samples in the blue branch are regarded as high TIL (red: relative high expression, green: relative low expression), and are discarded from further analyses. Top row indicates mutation status (red: BRCA1, blue: BRCA2, green: CHEK2, grey: BRCAX), bottom row indicates intrinsic subtype (grey: luminal, black: basal). b, correlation plot for immune signature mRNA values and TIL percentages as determined by an experienced pathologist (rs = 0.74, p-value < 0.001), colors represent mutation status

Copy number and LOH profiling

High resolution copy number and LOH profiling by means of SNP array analysis was performed to gain insight into the genomic characteristics of CHEK2*1100delC as compared to BRCAX breast cancers. Intrinsic sub-typing of breast carcinomas based on global gene expression profiles has revealed large differences between the basal-like, ERBB2/Her2Neu and luminal subtypes regarding patterns of CNA's [13, 2325]. As CHEK2*1100delC breast cancers are found to be exclusively of the luminal subtypes [12], the analyses were restricted to these intrinsic subtypes to avoid subtype associated confounding effects on copy number profiling.

Unsupervised hierarchical clustering of copy number profiles of all luminal CHEK2*1100delC and BRCAX samples, i.e. including samples with high TILs, suggests a great degree of heterogeneity amongst the CHEK2*1100delC breast cancers comparable to that seen in the BRCAX breast cancers (Fig. 2). The copy number aberration clustering roughly divides the samples into three groups, as indicated in Fig. 2. In group 1 many tumors are seen to have similar CNAs, including regions of copy number gain of chromosomal arms 1q, 8q, and 16p and copy number losses of chromosomal arms 8p and 16q. A second group (group 2) of tumors was found to have a more unstable CNA profile with focal amplifications on chromosome 17 (ERBB2) and concomitant high gene expression values for ERBB2 and nearby genes (GRB7, STARD3), while a third group (group 3) is characterized predominantly by high TIL samples with very few CNAs. In agreement with the copy number analysis results, heterogeneous patterns of LOH with no frequent reoccurring regions were identified (data not shown).

Fig. 2

Genomic profiles of CHEK2*1100delC and BRCAX breast tumors. Hierarchical clustering of CNA data. On the vertical axis, chromosomes 1 to X are displayed. Copy number gains are indicated in dark red (copy number amplifications (copy number > 6) in light red), losses in blue, and copy neutral regions in grey. TIL (black: high TIL, grey: low TIL) and mutation status (green: CHEK2*1100delC, grey: BRCAX) are indicated for each sample in the top rows by color

Supervised class comparison of the copy number profiles of low TIL CHEK2*1100delC (n = 14) and BRCAX (n = 34) breast cancers identified a small number of genomic regions with differential CNAs (Fig. 3). Most notable is the copy number loss of chromosome 1p which overlaps with a previously reported region [19]. However, most of the identified regions are marginally statistically significant and have CNAs at very low frequencies in the two tumor groups. Interestingly, a small region of (focal) copy number gain on chromosome 17 (including the ERBB2 locus) is found in almost half (6/14) of the CHEK2*1100delC breast cancers.

Fig. 3

Copy number frequency plots of 14 CHEK2*1100delC and 34 BRCAX low TIL breast tumors. a, the frequency (x-axis) of gains (red) and losses (blue) are displayed along chromosomes 1 to X (y-axis) for 14 CHEK2*1100delC (top panel) and 34 BRCAX (bottom panel) breast cancers. b, Fisher's exact test is used to determine regions of differential copy number aberrations between the CHEK2*1100delC and BRCAX breast cancers. The dotted line represents a p-value threshold of 0.05 (not corrected for multiple testing). The regions above the threshold are considered to be significantly different between the groups. P-values are - log 10 transformed

Copy number losses on chromosome 22 (including the CHEK2 locus) are found in half of the CHEK2*1100delC breast cancers, of which 4 showed LOH at the CHEK2 locus. However, copy number losses on chromosome 22 are also frequently found for the BRCAX breast cancers (25 % of the cases). Furthermore, samples with copy number losses on chromosome 22 were seen in all 3 groups as identified by unsupervised hierarchical clustering of copy number data.

Gene expression analysis

Gene expression analysis by means of ANOVA was restricted to low TIL samples of the luminal intrinsic subtypes, with mutation status as single factor (14 CHEK2*1100delC vs. 34 BRCAX). This resulted in 6 differentially expressed probe-sets passing a step-up FDR p-value of 0.05 (See Table 1). None of the differentially expressed genes between the CHEK2*1100delC and BRCAX breast cancers were found to overlap with the CHEK2 signature reported by Muranen et al. [19].

Table 1 Differentially expressed probe-sets between CHEK2a1100delC and BRCAX breast cancers


We performed high-resolution copy number, LOH and gene expression profiling of CHEK2*1100delC breast cancers to better understand the tumorigenesis to which the germ line CHEK2 deficiency predisposes. Our analysis was restricted to breast cancers of the luminal intrinsic subtypes as CHEK2*1100delC breast cancers are found to be exclusively of these mRNA based subtypes. Furthermore, samples were selected for low numbers of TILs based on a mRNA immune signature.

The copy number profiles of CHEK2*1100delC breast carcinomas were found to be heterogeneous and largely resemble those of the BRCAX breast carcinomas. The largest group of tumors has characteristic copy number gains of chromosomal arms 1q, 8q and 16p and copy number losses of chromosomal arms 8p and 16q. These CNAs have frequently been reported for breast carcinomas of the luminal intrinsic subtypes [13, 2325]. A second group was found to have a more unstable CNA profile and focal amplifications of the ERBB2 genomic region. The observed focal amplifications of the ERBB2 genomic region and the increase in gene expression levels of the genes herein suggest that a proportion of CHEK2*1100delC breast cancers could be related to the ERBB2/Her2Neu intrinsic subtype. A third group was found to be largely CNA devoid; most of these samples were identified to have high numbers of tumor infiltrating lymphocytes (TILs). In previous work we identified a similar CNA devoid group of (BRCA1-mutated) basal-like breast carcinomas, which proved to be caused by the presence of large numbers of TILs in these samples.

Compared to the BRCA1 and BRCA2 profiles reported in literature and our previous study, copy number aberrations are infrequently seen in CHEK2*1100delC breast cancers. The most frequently observed aberrations in CHEK2*1100delC breast cancers are those seen in many breast cancers of the luminal intrinsic subtypes. Also, hierarchical clustering showed a great degree of heterogeneity of copy number profiles amongst the CHEK2*1100delC breast cancers, while BRCA1-mutated breast cancers frequently co-cluster in hierarchical cluster analysis [13].

Few characteristic CNAs for CHEK2*1100delC breast cancers were found. In contrast to our BRCA1 profiling results [18], most of these CNAs in CHEK2*1100delC breast cancers are seen at very low frequencies and are marginally statistically significant. With the exception of copy number loss of chromosomal arm 1p, which was found more frequently in CHEK2*1100delC breast cancers. Furthermore, the observed copy number amplifications overlapping the ERBB2 gene in the CHEK2*1100delC samples fits well with the reported over-expression of the ERBB2 gene in half of the CHEK2*1100delC homozygous cases [26].

For the most part, our findings are comparable to previously reported findings on the genomic characteristics of CHEK2*1100delC breast cancers by Muranen et al. [19]. This includes the copy number loss of chromosomal arm 1p seen in CHEK2*1100delC breast cancers, and LOH/loss at the CHEK2 locus in only part of the tumors. In line with this, Suspitsin et al. concluded that tumor-specific loss of the wild-type allele is not characteristic for breast cancers arising in CHEK2 mutation carriers as well as for other moderate risk genes. [27]. In contrast, the reported copy number gains of the CHEK2 region in CHEK2*1100delC breast cancers were not observed in our data, we only observed normal copy number and copy number losses.

In addition, genome wide gene expression analysis identified a small number of genes to be differentially expressed between CHEK2*1100delC and BRCAX breast cancers, of which none overlap with the previously reported CHEK2 gene expression signature by Muranen et al [19]. Furthermore, only 2 genes are seen to overlap with a reported 40-gene CHEK2 signature found in the study by Nagel et al. [12]. This difference is most likely due to sample selection criteria. Where our analysis is restricted to low-TIL BRCAX and CHEK2*1100delC mutated breast cancers of the luminal subtypes, Nagel et al. performed their analysis on all hormone receptor positive breast cancers, including high-TIL and BRCA1/BRCA2 mutated samples. Furthermore, we applied a stringent false discovery p_value cut-off of 0.05, opposed to a FDR p_value of 0.25 by Nagel et al. Also, there is no overlap in the CHEK2 gene signatures reported by Muranen et al. and Nagel et al.

The most significant differentially expressed gene in the 40-gene CHEK2 signature is the CHEK2 gene itself. We found CHEK2 gene expression to be particularly high in the high-TIL BRCAX samples, this could explain why, after sample selection, we do not find the CHEK2 gene to be differentially expressed.

All differentially expressed genes in our analysis were found to be relatively higher expressed in the CHEK2*1100delC samples as compared to the BRCAX samples, but were not found in genomic regions of copy number gain in the CHEK2*1100delC samples. We found no direct links between these differentially expressed genes and CHEK2 gene function, except for possibly the CENPJ gene. This gene encodes a protein that belongs to the centromere protein family. The protein plays a structural role in the maintenance of centrosome integrity and normal spindle morphology [28]. Recently, CHEK2 has been reported to be involved in the regulation of proper mitotic spindle formation through phosphorylation of BRCA1, hereby ensuring chromosomal stability [29].

For BRCA1 mutated breast cancers, specific CNAs are reported. Complete loss of BRCA1 leads to severe proliferation defects in normal cells, proving lethal during embryonic development [30]. Therefore, it seems likely that BRCA1-mutated cells acquire survival factors that allow BRCA1-deficient tumor cells to expand. CNAs are well known mechanisms to acquire such factors. For instance, in previous work we identified a region of copy number loss on chromosome 15q in all BRCA1-mutated samples, which likely acts on the reported BRCA1 associated loss of 53BP1 [31]. In contrast to BRCA1, CHEK2 deficiency is not lethal as evidenced by CHEK2*1100delC homozygous carriers in the population and the viability of Chek2 knockout mice [32, 33]. Therefore, specific survival factors for CHEK2 mutated cells are not required during tumorigenesis if the wild type allele for CHEK2 is lost. However, it remains unclear to what extent loss of the wild type allele of CHEK2 is necessary for tumorigenesis. Although CHEK2*1100delC homozygous female carriers are more susceptible to tumor development [26], analysis of tumors from CHEK2*1100delC heterozygous carriers show a heterogeneous pattern of LOH/loss at the CHEK2 locus. It remains uncertain whether this reflects two different tumor groups, i.e. one with complete loss of wild type CHEK2 and thereby CHEK2 driven tumorigenesis and one without thereby representing sporadic tumors, or that loss of one CHEK2 allele is sufficient to drive tumorigenesis. Furthermore, loss of the CHEK2 wild type allele could be a non-driver event.


In conclusion, in contrast to BRCA1/2 breast cancers, no apparent predominant specific CNA profile nor robust gene expression profile for CHEK2*1100delC breast cancers was found. This could in part result from the small number of CHEK2*1100delC breast cancer samples used in this study. However, in our previous work, an even smaller number of BRCA1-mutated basal-like breast cancers proved sufficient to identify BRCA1-associated CNAs. Nevertheless, we cannot exclude the possibility that multiple different CHEK2 specific profiles do exist. Larger sample sizes are needed to investigate this.

The results show no specific tumorigenic events regarding CHEK2 tumorigenesis, except for copy number loss of chromosomal arm 1p. However, gene expression analysis did not hint towards any potential driver genes in this region. Further studies are needed to establish whether this loss is indeed associated with CHEK2 breast tumors. Also, gene expression analysis identified a very small number of differentially expressed genes between the CHEK2*1100delC and BRCAX breast cancers, of which, except for possibly CENPJ, none seem to have a putative role in CHEK2 related tumorigenesis based on what is known in literature. This small number of differentially expressed genes can also, in part, be due to the small amount of CHEK2*1100delC samples used in the analysis, and need to be validated.

Based on our previous work on BRCA1 tumors and the current study on CHEK2 tumors we postulate a model in which breast tumors with a defect in an essential gene such as BRCA1 or BRCA2, result in copy number profiles that reflect both the tumor subtype and specific surviving factors while breast tumors with a defect in a non-essential gene such as CHEK2, result in copy number profiles that largely reflect the tumor subtype. In this model the presence of a germ line CHEK2*1100delC mutation might be regarded as an accelerator of tumorigenesis leading to CNA profiles comparable to that of luminal sporadic breast tumors.



Tumor infiltrating lymphocytes


Loss of heterozygosity


Familial non-BRCA1/BRCA2/CHEK2*1100delC mutated


Copy number aberration


Estrogen/progesterone receptor


False discovery rate


Mirrored BAF profiles


Fisher’s exact test


  1. 1.

    Ellsworth RE, Decewicz DJ, Shriver CD, Ellsworth DL. Breast cancer in the personal genomics era. Curr Genomics. 2010;11:146–61.

  2. 2.

    Antoniou AC, Casadei S, Heikkinen T, Barrowdale D, Pylkas K, Roberts J, et al. Breast-cancer risk in families with mutations in PALB2. N Engl J Med. 2014;371:497–506.

  3. 3.

    Meijers-Heijboer H, van den Ouweland A, Klijn J, Wasielewski M, de Snoo A, Oldenburg R, et al. Low-penetrance susceptibility to breast cancer due to CHEK2(*)1100delC in noncarriers of BRCA1 or BRCA2 mutations. Nat Genet. 2002;31:55–9.

  4. 4.

    CHEK2 Breast Cancer Case-Control Consortium. CHEK2*1100delC and susceptibility to breast cancer: a collaborative analysis involving 10,860 breast cancer cases and 9,065 controls from 10 studies. Am J Hum Genet 2004, 74:1175-1182.

  5. 5.

    Cybulski C, Wokolorczyk D, Jakubowska A, Huzarski T, Byrski T, Gronwald J, et al. Risk of breast cancer in women with a CHEK2 mutation with and without a family history of breast cancer. J Clin Oncol. 2011;29:3747–52.

  6. 6.

    Bartek J, Lukas J. Chk1 and Chk2 kinases in checkpoint control and cancer. Cancer Cell. 2003;3:421–9.

  7. 7.

    Staalesen V, Falck J, Geisler S, Bartkova J, Borresen-Dale AL, Lukas J, et al. Alternative splicing and mutation status of CHEK2 in stage III breast cancer. Oncogene. 2004;23:8535–44.

  8. 8.

    Anczukow O, Ware MD, Buisson M, Zetoune AB, Stoppa-Lyonnet D, Sinilnikova OM, et al. Does the nonsense-mediated mRNA decay mechanism prevent the synthesis of truncated BRCA1, CHK2, and p53 proteins? Hum Mutat. 2008;29:65–73.

  9. 9.

    Oldenburg RA, Kroeze-Jansema K, Kraan J, Morreau H, Klijn JG, Hoogerbrugge N, et al. The CHEK2*1100delC variant acts as a breast cancer risk modifier in non-BRCA1/BRCA2 multiple-case families. Cancer Res. 2003;63:8153–7.

  10. 10.

    Merajver SD, Frank TS, Xu J, Pham TM, Calzone KA, Benett-Baker P, et al. Germline BRCA1 mutations and loss of the wild-type allele in tumors from families with early onset breast and ovarian cancer. Clin Cancer Res. 1995;1:539–44.

  11. 11.

    de Bock GH, Schutte M, Krol-Warmerdam EM, Seynaeve C, Blom J, Brekelmans CT, et al. Tumour characteristics and prognosis of breast cancer patients carrying the germline CHEK2*1100delC variant. J Med Genet. 2004;41:731–5.

  12. 12.

    Nagel JH, Peeters JK, Smid M, Sieuwerts AM, Wasielewski M, de Weerd V, et al. Gene expression profiling assigns CHEK2 1100delC breast cancers to the luminal intrinsic subtypes. Breast Cancer Res Treat. 2012;132:439–48.

  13. 13.

    Jonsson G, Staaf J, Vallon-Christersson J, Ringner M, Holm K, Hegardt C, et al. Genomic subtypes of breast cancer identified by array-comparative genomic hybridization display distinct molecular and clinical characteristics. Breast Cancer Res. 2010;12:R42.

  14. 14.

    Tirkkonen M, Johannsson O, Agnarsson BA, Olsson H, Ingvarsson S, Karhu R, et al. Distinct somatic genetic changes associated with tumor progression in carriers of BRCA1 and BRCA2 germ-line mutations. Cancer Res. 1997;57:1222–7.

  15. 15.

    Joosse SA, Brandwijk KI, Devilee P, Wesseling J, Hogervorst FB, Verhoef S, et al. Prediction of BRCA2-association in hereditary breast carcinomas using array-CGH. Breast Cancer Res Treat. 2010.

  16. 16.

    van Beers EH, van Welsem T, Wessels LF, Li Y, Oldenburg RA, Devilee P, et al. Comparative genomic hybridization profiles in human BRCA1 and BRCA2 breast tumors highlight differential sets of genomic aberrations. Cancer Res. 2005;65:822–7.

  17. 17.

    Wessels LF, van Welsem T, Hart AA, van't Veer LJ, Reinders MJ, Nederlof PM. Molecular classification of breast carcinomas by comparative genomic hybridization: a specific somatic genetic profile for BRCA1 tumors. Cancer Res. 2002;62:7110–7.

  18. 18.

    Massink MPG, Kooi IE, van Mil SE, Jordanova ES, Ameziane N, Dorsman JC, van Beek DM, van der Voorn JP, Sie D, Ylstra B, van Deurzen CH, Martens JW, Smid M, Sieuwerts AM, de Weerd V, Foekens JA, van den Ouweland AM, van Dyk E, Nederlof PM, Waisfisz Q, Meijers-Heijboer H: Proper genomic profiling of (BRCA1-mutated) basal-like breast carcinomas requires prior removal of tumour infiltrating lymphocytes. Molecular Oncology (2015),

  19. 19.

    Muranen TA, Greco D, Fagerholm R, Kilpivaara O, Kampjarvi K, Aittomaki K, et al. Breast tumors from CHEK2 1100delC-mutation carriers: genomic landscape and clinical implications. Breast Cancer Res. 2011;13:R90.

  20. 20.

    van Diest PJ. No consent should be needed for using leftover body material for scientific purposes. For. BMJ. 2002;325:648–51.

  21. 21.

    Sorlie T, Tibshirani R, Parker J, Hastie T, Marron JS, Nobel A, et al. Repeated observation of breast tumor subtypes in independent gene expression data sets. Proc Natl Acad Sci U S A. 2003;100:8418–23.

  22. 22.

    Staaf J, Lindgren D, Vallon-Christersson J, Isaksson A, Goransson H, Juliusson G, et al. Segmentation-based detection of allelic imbalance and loss-of-heterozygosity in cancer cells using whole genome SNP arrays. Genome Biol. 2008;9:R136.

  23. 23.

    Smid M, Hoes M, Sieuwerts AM, Sleijfer S, Zhang Y, Wang Y, et al. Patterns and incidence of chromosomal instability and their prognostic relevance in breast cancer subtypes. Breast Cancer Res Treat. 2011;128:23–30.

  24. 24.

    Waddell N, Arnold J, Cocciardi S, da Silva L, Marsh A, Riley J, et al. Subtypes of familial breast tumours revealed by expression and copy number profiling. Breast Cancer Res Treat. 2010;123:661–77.

  25. 25.

    Bergamaschi A, Kim YH, Wang P, Sorlie T, Hernandez-Boussard T, Lonning PE, et al. Distinct patterns of DNA copy number alteration are associated with different clinicopathological features and gene-expression subtypes of breast cancer. Genes Chromosomes Cancer. 2006;45:1033–40.

  26. 26.

    Adank MA, Jonker MA, Kluijt I, van Mil SE, Oldenburg RA, Mooi WJ, et al. CHEK2*1100delC homozygosity is associated with a high breast cancer risk in women. J Med Genet. 2011;48:860–3.

  27. 27.

    Suspitsin EN, Yanus GA, Sokolenko AP, Yatsuk OS, Zaitseva OA, Bessonov AA, et al. Development of breast tumors in CHEK2, NBN/NBS1 and BLM mutation carriers does not commonly involve somatic inactivation of the wild-type allele. Med Oncol. 2014;31:828.

  28. 28.

    Lin YC, Chang CW, Hsu WB, Tang CJ, Lin YN, Chou EJ, et al. Human microcephaly protein CEP135 binds to hSAS-6 and CPAP, and is required for centriole assembly. EMBO J. 2013;32:1141–54.

  29. 29.

    Stolz A, Ertych N, Kienitz A, Vogel C, Schneider V, Fritz B, et al. The CHK2-BRCA1 tumour suppressor pathway ensures chromosomal stability in human somatic cells. Nat Cell Biol. 2010;12:492–9.

  30. 30.

    Evers B, Jonkers J. Mouse models of BRCA1 and BRCA2 deficiency: past lessons, current understanding and future prospects. Oncogene. 2006;25:5885–97.

  31. 31.

    Bouwman P, Aly A, Escandell JM, Pieterse M, Bartkova J, van der Gulden H, et al. 53BP1 loss rescues BRCA1 deficiency and is associated with triple-negative and BRCA-mutated breast cancers. Nat Struct Mol Biol. 2010;17:688–95.

  32. 32.

    Hirao A, Cheung A, Duncan G, Girard PM, Elia AJ, Wakeham A, et al. Chk2 is a tumor suppressor that regulates apoptosis in both an ataxia telangiectasia mutated (ATM)-dependent and an ATM-independent manner. Mol Cell Biol. 2002;22:6521–32.

  33. 33.

    Takai H, Naka K, Okada Y, Watanabe M, Harada N, Saito S, et al. Chk2-deficient mice exhibit radioresistance and defective p53-mediated transcription. EMBO J. 2002;21:5195–205.

Download references


Funded by the Netherlands Genomics Initiative/Netherlands Organization for Scientific Research NWO. Hanne Meijers-Heijboer is a fellow from the NWO Vidi Research Program. The public foundation that supported the study had no role in the design and conduct of the study; in the collection, management, analysis, and interpretation of the data; or in data preparation, review, or approval of the manuscript.

Author information

Correspondence to Quinten Waisfisz.

Additional information

Competing interests

The authors declare that they have no competing interests.

Authors’ contributions

MPGM contributed to study design, data analysis and interpretation, generation of figures, and writing of the manuscript. IEK contributed to data analysis and generation of figures. HMH, JWM, QW all participated in the conceptualization of the study/study design and sample selection/acquisition. QW participated in the conceptualization and design of the study, data interpretation, manuscript preparation and supervised the project. All authors read and approved the final manuscript.
